Vůz na beton nový Constmach Single Shaft Concrete Mixer (Paddle Mixer)

You can Call us 24/7 for a single shaft concrete mixer for sale.

Concrete mixers offer robust and durable solutions for all kinds of projects. CSS series single shaft concrete mixers attract attention with their innovative designs that provide high performance and reliability. All models of this series are manufactured using high-quality materials and show superior durability even in the most demanding conditions.

CSS series single shaft concrete mixers meet a wide range of needs by offering fresh and compressed concrete volumes in different capacities. Features such as an automatic lubrication system and a hydraulic discharge cover increase operational efficiency while facilitating maintenance operations. In addition, maintenance covers with safety sensors keep safety at the highest level.

The 10-15 mm thick Hardox 450 materials used in the side body wear plates and the 15-30 mm Ni-Hard materials preferred in the main body and mixing arm wear plates ensure the long service life of the mixers. These features guarantee that the mixers maintain their performance even in all kinds of harsh conditions.

CSS series mixers offer maximum efficiency and durability with every detail. models with different capacities from 750 liters loading volume to 3000 liters offer solutions suitable for the needs of projects. These mixers, equipped with various motor options ranging from 18.5 kW motor power to 2 x 37 kW motor power, aim to provide the highest performance.

CSS series mixers equipped with high quality and durable materials can be used safely at every stage of your projects. Each model is designed to offer superior performance and long-lasting use. If you are looking for a concrete mixer that you can use safely in your projects, CSS series mixers are for you. Take your business one step further with high performance, durability and ease of use.

CSS - 0.5 Model Technical Specifications

Loading Volume: 750 lt
Fresh Concrete Volume: 625 lt
Compacted Concrete Volume: 500 lt
Engine Power: 18.5 kW
Side Body Wear Plates: 10 mm Hardox 450
Main Body Wear Plates: 15 mm Ni Hard
Mixing Handle Wear Plates: 25 mm Ni-Hard
Automatic Lubrication System: Available
Hydraulic Discharge Cover: Available
Maintenance Cover with Safety Sensor: Available

CSS - 1 Model Technical Specifications

Loading Volume: 1.500 lt
Fresh Concrete Volume: 1.250 lt
Compacted Concrete Volume: 1.000 lt
Engine Power: 37 kW
Side Body Wear Plates: 15 mm Hardox 450
Main Body Wear Plates: 15 mm Ni Hard
Mixing Handle Wear Plates: 25 mm Ni-Hard
Automatic Lubrication System: Available
Hydraulic Discharge Cover: Available
Maintenance Cover with Safety Sensor: Available

CSS - 2 Model Technical Specifications

Loading Volume: 3,000 lt
Fresh Concrete Volume: 2.500 lt
Compacted Concrete Volume: 2.000 lt
Engine Power: 2 x 37 kW
Side Body Wear Plates: 15 mm Hardox 450
Main Body Wear Plates: 20 mm Ni Hard
Mixing Handle Wear Plates: 30 mm Ni-Hard
Automatic Lubrication System: Available
Hydraulic Discharge Cover: Available
Maintenance Cover with Safety Sensor: Available
