Betonový agregát nový Constmach 50 Ton Capacity Cement Silo

You can call us 24/7 for a 50-ton cement silo for sale.

Our CS-50 model cement silo offers performance exceeding standards with its robust structural features and 50 ton capacity. In particular, this product, which is designed in accordance with wide areas of use, has been developed in such a way as to perfectly respond to various needs. with a height of 15000 mm and a diameter of 2400 mm, this silo has a volume of 38 m3, which offers an effective storage capacity during use.

With its legs made of four sturdy steel pipes and supports consisting of NPL 60 mm metal sheet, our CS-50 model raises the bar in durability. weighing 6160 kg, the silo is specially designed to keep its stability at the maximum level. The body, which is made of ST-37 metal plate, is supported by conical parts, top cover and 5 mm thick strong steel C channels.

The features inside the silo are equipped with user-friendly details; for example, the filling pipes are made of 4" steel, providing ease of use. In addition, features such as an internal manhole and an external man hole facilitate maintenance and control operations. Moreover, with its design that prioritizes safety, there is a guardrail and a large maintenance platform on the silo roof.

Each CS-50 silo is subjected to structure analysis and specially produced according to approved projects. This process guarantees to provide a suitable and reliable solution for the needs of each user. Offering functionality, safety and durability Decoupled, the CS-50 is an excellent investment opportunity with high efficiency and low maintenance costs in the long term.

CS-50 50 Ton Capacity Cement Silo Technical Specifications

Silo Capacity 50 Tons, 38 M3​
Silo Height 15000 mm
Silo Diameter Ø 2400 mm
Number of Silo Legs 4
Silo Outlet Diameter Ø 300 mm
Number of Components 8
Silo Weight 6160 Kg
Silo Foot Material 168 X 5 Mm, Steel Pipe
Silo Foot Supports Npl 60 Mm Metal Sheet
Silo Foot Plates 15 Mm Metal Sheet
Taper Part Support Material 100 Mm Steel C Channel
Conical Part Material St - 37 - 5 Mm Metal Sheet
Silo Body Material St - 37 - 4 Mm Metal Sheet
Silo Top Cover Material St - 37 - 4 Mm Metal Sheet
Filling Pipe 4" Steel Pipe Up to the Silo Foot
Internal Manhole Is Available
Dental Man Hole Is Available
There is a Railing on the Silo Roof
Maintenance Platform Is Available
Structure Analysis Is Carried Out For The Silos And The Production Process Is Carried Out Depending On The Approved Projects.
